3.1.2
The keys used when operating via the terminal are as follows:
If the RS-232C cable is connected while the controller is powered on, press
[Ctrl] [L] to refresh the screen information.
The initial screen appears when the controller finishes self-test and
is properly initialized.
emulation mode, then press [ENTER] to enter the Main Menu.
Choose a functional item from the main menu to begin configuring
your RAID.
Connecting Terminal
Starting RS-232C Terminal Emulation
To select options
[Enter]
To go to a submenu or to execute a selected option
[Esc]
To escape and go back to the previous menu
[Ctrl] [L]
The controller will refresh the screen information
IMPORTANT!
Use
arrow keys to select terminal
3-3
