10.3.1 Via Front Panel Keypad

Redundant Configuration Using Automatic Setting

Power-on Controller 1. Make sure Controller 2 is powered-off.

1. Enable Redundant Controller

Press [ENT] for two seconds on the front panel of
controller 1 to enter the main menu. Use
to navigate through the menus. Choose "View
and Edit Peripheral Dev.. (View and Edit
Peripheral Devices)," then press [ENT].
Choose "Set Peripheral Devices Entry," then press
[ENT].
Choose "Redundant Ctlr Function__", and then
press [ENT]. (Note: The current setting will be
displayed on the LCD) If this controller has never
been set as a redundant controller before, the
default setting of the redundant controller
function is "Disabled." The message "Redundant
Ctlr Function Disable" will be displayed on the
LCD. Press [ENT] to proceed.

Autoconfig.

The message "Enable Redundant Ctlr: Autocfg?"
will appear. Use
available options ("Primary," "Secondary," or
"Autocfg"), then press [ENT] for two seconds to
select "Autocfg."
For
connected, status will be indicated as "Inactive."
Once set, press [ESC] for several times to return
to the main menu.

2. Controller Unique ID

Enter
"Controller Parameters".
"Ctlr Unique ID- xxxxx".
This value will be used to generate a controller-
unique WWN node name and port names and to
identify the controller during the failover process.
Enter a hex number from 0 to FFFFF and press
[ENTER].
different for each controller.
10-20
or
the other controller
"View and Edit
The value you enter should be
or
to scroll through the
is currently not
Config Parms"->
Use or to find
View and Edit
Peripheral Dev
Set Peripheral
Devices Entry
Redundant Ctlr
Function Disable
Enable Redundant
Ctlr: Autocfg
Redundant Ctlr:
Autocfg Inactive
View and Edit
Config Parms
Controller
Parameters ..
Ctlr Unique
ID- 00012 ?
