3.1.1
Take the following steps to change the baud rate using the front
panel keypad:
Press ENT for two seconds to enter the
Main Menu.
"View and Edit Configuration ..", then
press ENT.
Select "Communication Parameters ..",
then press ENT.
Select "RS-232 Configuration ..", then
press ENT.
Select "COM1 Configuration ..", then
press ENT.
Select "Baud-rate 38400 ..", then press
ENT.
The baud rate default is 38400. If other
baud rate is preferred, press
select the baud rate, then press ENT for 2
seconds to confirm the selected baud
rate.
RAID array and your terminal computer.
3-2

Configuring RS-232C Connection via Front Panel

Press
Set identical baud rate to your
The following baud rates are available: 2400, 4800, 9600, 19200
and 38400.
Terminal connection should work properly using the above
setting. You may check the following options in your COM port
configuration if you encounter problems:
1. "Comm Route Dir ..": The communication route should be
configured as "direct to port" instead of "through PPP".
2. "Term Emul. Enab ..": Make sure the terminal function has
not been accidentally disabled.
View and Edit
or to select
Config Parms
Communication
Parameters
RS-232C
Configuration ..
COM1
Configuration ..
Baud-rate
Baud-rate 38400
or to
Change to 19200?
..
38400
..
