Compaq External RAID Controller & Subsystem Infortrend Operation Manual page 133

1.
2.
3.
4.
5.
A prompt will display the
mapping you wish to create.
Choose Yes to confirm the
LUN mapping you selected.
The detail in the confirm box
reads: partition 0 of logical
volume 0 will map to LUN 0
of SCSI ID 0 on host channel 0.
Continue to map other partitions to host LUNs.
With any of the Host ID/LUN successfully associated with a logical
capacity, the "No Host LUN" message in the LCD screen will
change to "Ready."
If your controller has not been configured with a host channel and
assigned with SCSI ID, please move on to section 7.12
and Editing SCSI Channels."
7-14
A list of LUN entries and their respective mappings will be
displayed. To map a host LUN to a logical volume's partition,
select an available LUN entry (one not mapped yet) by moving
the cursor bar to the LUN, then press [ENTER].
A list of available logical volumes displays. Move the cursor bar
to the desired logical unit, then press [ENTER].
A list of available partitions will prompt. Move cursor bar to the
desired partition, then press [ENTER].
partitioned the logical volume, the whole capacity will be
displayed as one logical partition.
When prompted to "Map
Host LUN," press [ENTER]
to proceed. For access control over Fibre network, find in
Chapter 8 details about "Create Host Filter Entry."
When prompted to "Map Logical Volume?," select Yes to
continue.
If you have not
