Channel:
Warning:
2-Line LCD Chl:_ Redundant Loop Connection Error Detected on ID:_
Terminal
[113f] CHL:_ ALERT: Redundant Loop Connection Error Detected on
ID:_
Event Type
What
One of the dual loop members may have failed or been disconnected.
Happens?
Make sure all channels are properly connected and topological
configuration properly set.
What to Check the redundant fibre channel loop connection is right.
Do?
2-Line LCD
Chl:_ SCSI Drive Channel ALERT: SCSI Channel Failure
Terminal
[113f] CHL:_ SCSI Drive Channel ALERT: SCSI Channel Failure
Event Type
What
Specific drive channel may have failed or disconnected.
Happens?
What to
Press <ESC> to clear the message.
Do?
2-Line LCD
Chl:_ Fibre Channel Loop Failure Detected
Terminal [113f] CHL:_ ALERT: Fibre Channel Loop Failure Detected
Event Type
What
Fibre channel loop failure is detected.
Happens?
What to
Press <ESC> to clear the message.
Do?
2-Line LCD Chl:_ Redundant Loop for Chl:_ Failure Detected
Terminal [113f] CHL:_ ALERT: Redundant loop for Chl:_ Failure Detected
Event Type
What
The pair loop has failed.
Happens?
What to
Press <ESC> to clear the message.
Do?
2-Line LCD Chl:_ Redundant Path for Chl:_ ID:_ Expected but Not Found
Terminal
[113f] CHL:_ ALERT: Redundant Path for Chl:_ ID:_ Expected but Not
Found
Event Type
What
Disconnection with the pair loop may have occurred.
Happens?
What to
Press <ESC> to clear the message.
Do?
Event Messages
"Alert !Warning
"Alert !Warning
"Alert !Warning
"Alert !Warning
"Alert !Warning
"Notification
"Notification
"Notification
"Notification
"Notification
D-15
