User Interface:

RAIDWatch on-board

RS-232C Terminal

Graphical User Interface
(Java-based GUI Manager)
External Interface API for
customized host-based
management
LCD Front Panel
Buzzer alarm

Remote Manageability:

Modem Support
Auto dial-out
Event dial-out to terminal
Event dial-out to pager
Terminal dial-in
Custom Inquiry Serial
Number
Remote Redundant
Controller Configuration
B-10
Out-of-band configuration via LAN. Browser
accessible configuration option by installing
RAIDWatch to reserved space on drive via ftp.
Supports terminal modes: ANSI, VT-100, ANSI Color.
Provides menu-driven user-friendly text-based
interface.
Provides user-friendly graphical interface.
Communicates with RAID controller via In-band
SCSI, In-band Fibre or SNMP (Windows-based GUI).
Customers can use Infortrend RAIDWatch or develop
their own GUI according to the "External Interface
Specification" (contact Infortrend support for this
OEM document).
Supported.
Provides easy access for user instinct operation.
Warns user when any failure or critical event occurs.
The COM 1 port of the controller can be connected to
a MODEM for remote manageability.
Supported. Can be configured to dial-out to a remote
terminal when controller is powered on – for remote
administration.
Supported. Can be configured to dial-out a remote
terminal when an event occurs.
Supported. Can be configured to dial-out a pager
number with message (user configured with AT
commands) when an event occurs.
Supported. Can be configured to accept a remote
terminal dial-in for remote administration.
Custom Inquiry Serial Number (for support of multi-
pathing software like Veritas, QLogic, etc)
Supported. Remote redundant controller
configuration (support fully automatic failback-user's
interaction free)
