MFX Parameters

Gate

Cuts the reverb's delay according to the volume of the sound sent into the effect.
Use this when you want to create an artificial-sounding decrease in the reverb's decay.
Parameter Value
Threshold 0–127
GATE, DUCK
Mode
Attack 0–127
0–127
Hold
Release 0–127
D100: 0W–D0:
Balance
100W
Level 0–127
130
Volume level at which the gate begins to close
Type of gate
GATE: The gate will close when the volume of the original sound decreases, cutting the original
sound.
DUCK (Duking): The gate will close when the volume of the original sound increases, cutting the
original sound.
Adjusts the time it takes for the gate to fully open after being triggered.
Adjusts the time it takes for the gate to start closing after the source sound falls beneath the
Threshold.
Adjusts the time it takes the gate to fully close after the hold time.
Volume balance between the direct sound (D) and the effect sound (W)
Output Level
Explanation
