2Tap Pandly (2 Tap Pan Delay) - Roland SH-4d Owner's Manual

MFX Parameters
Para
met
er
High -15–+15 [dB]
Gain
Bala D100: 0W–D0: 100W
nce
Leve 0–127
l

2Tap PanDly (2 Tap Pan Delay)

Parameter
Delay Sync OFF, ON
D. Time 1–2600
(ms)
D.Time Note(P.167)
（Nt）
-98–+98 [%]
Delay Fbk
200, 250, 315, 400, 500, 630, 800, 1000, 1250,
Dly HF 1600, 2000, 2500, 3150, 4000, 5000, 6300,
8000, BYPASS [Hz]
Dly1 Pan L64–63R
L64–63R
Dly2 Pan
Dly1 Lv 0–127
Dly2 Lv 0–127
Low Gain -15–+15 [dB]
High Gain -15–+15 [dB]
D100: 0W–D0: 100W
Balance
Level 0–127
134
Value
Value
Amount of boost/cut for the high-frequency range
Volume balance between the direct sound (D) and the delay sound (W)
Output Level
If this is ON, the delay synchronizes with the tempo.
Adjusts the time until the second delay sound is heard.
Adjusts the proportion of the delay sound that is fed back into the
effect.
Negative (-) settings will invert the phase.
Adjusts the frequency above which sound fed back to the effect is
filtered out. If you don't want to filter out any high frequencies, set
this parameter to BYPASS.
Adjusts the stereo location of delay 1.
Adjusts the stereo location of delay 2.
Adjusts the volume of delay 1.
Adjusts the volume of delay 2.
Amount of boost/cut for the low-frequency range
Amount of boost/cut for the high-frequency range
Adjusts the volume balance between the sound that is sent
through the delay (W) and the sound that is not sent through the
delay (D).
Output Level
Explanation
Explanation
