Roland SH-4d Owner's Manual page 175

Parameter Value
0.2–9.0
Hi Q
GM2 Reverb
Parameter
SMALL ROOM,
MEDIUM ROOM,
LARGE ROOM,
Char
MEDIUM HALL,
LARGE HALL,
PLATE
Time 0–127
Gated Reverb
Parameter Value
NORMAL
REVERSE
Type
SWEEP1
SWEEP2
Pre Delay 0.0–100.0 [ms]
Gate Time 5–500 [ms]
Shimmer Reverb
Parameter Value
Low Damp -50–+50
High Damp -50–+50
Time 0.1–10.0 [s]
Density 1–10
Pre Delay 0–200 [ms]
Modulation Rate 0–100
Modulation 0–100
Depth
-24–+24
Pitch1 Coarse
[semi]
-24–+24
Pitch2 Coarse
[semi]
-98–+98 [%]
Pitch1 Feedback
-98–+98 [%]
Pitch2 Feedback
Level 1 0–100
Level 2 0–100
16, 20, 25, 32, 40, 50, 63, 80, 100, 125, 160, 200, 250, 315, 400, 500, 630, 800, 1000, 1250, 1600, 2000, 2500, 3150, 4000,
(*1)
5000, 6300, 8000, 10000, 12500, 15000 [Hz], BYPASS
BYPASS, 16, 20, 25, 32, 40, 50, 63, 80, 100, 125, 160, 200, 250, 315, 400, 500, 630, 800, 1000, 1250, 1600, 2000, 2500,
(*2)
3150, 4000, 5000, 6300, 8000, 10000, 12500, 15000 [Hz]
(*3) 1000, 1250, 1600, 2000, 2500, 3150, 4000, 5000, 6300, 8000 [Hz]
160, 200, 250, 320, 400, 500, 640, 800, 1000, 1250, 1600, 2000, 2500, 3200, 4000, 5000, 6400, 8000, 10000, 12500 [Hz],
(*4)
BYPASS
(*5) 50, 64, 80, 100, 125, 160, 200, 250, 320, 400, 500, 640, 800, 1000, 1250, 1600, 2000, 2500, 3200, 4000 [Hz]
(*6) 4000, 5000, 6400, 8000, 10000, 12500 [Hz]
Sets the bandwidth of the high frequency range.
Higher values make the bandwidth narrower.
Value
This selects the reverb type.
Adjusts the decay length of the reverb sound.
This is a standard gate reverb.
This is a reverb for which the sound ramps up in volume.
The reverb sound moves from right to left.
The reverb sound moves from left to right.
Adjusts the delay time from when the direct sound plays until the reverb sound is heard.
Adjusts the decay length of the reverb sound.
Adjusts how much to attenuate the low-frequency portion of the reverb.
Adjusts how much to attenuate the high-frequency portion of the reverb.
Adjusts the decay length of the reverb sound.
Adjusts the density of the reverb sound.
Adjusts how long it takes until the reverb sound is heard, after the direct sound plays.
Adjusts the speed at which the reverb sound is modulated.
Adjusts the depth to which the reverb sound is modulated.
Adjusts the amount of pitch shift applied for pitch shift 1 (in semitones).
Adjusts the amount of pitch shift applied for pitch shift 2 (in semitones).
Adjusts the proportion of the delay sound that is fed back into pitch shift 1. Negative (-)
settings invert the phase.
Adjusts the proportion of the delay sound that is fed back into pitch shift 2. Negative (-)
settings invert the phase.
Adjusts the volume of pitch shift 1.
Adjusts the volume of pitch shift 2.
Explanation
Explanation
Explanation
Explanation
PATTERN REVERB
175
