Chord - Roland SH-4d Owner's Manual

Parameter
[OSC 2] slider
Position Env Atk
[OSC 3] slider
Position Env Dcy
Position Env [OSC 4] slider
Depth

CHORD

Parameter Controllers
Coarse PITCH
Tune
SHIFT+PITCH
Fine Tune
TIMBRE
Balance
[OSC 1] slider
Chord
Voicing [OSC 2] slider
[OSC 3] slider
Pulse
Width
[OSC 4] slider
PWM
Depth
[OSC 1]–[OSC 4]
Waveform
buttons
-
Fat
Controllers Value
0–1023 Sets the attack time for the envelope that's applied at the wave
0–1023 Sets the decay time for the envelope that's applied at the wave
0–63
Value
-24–+24
-50–+50
0–255
Major, 6th, 7th, Maj7, M7 (5), minor, m6, m7,
mMaj7, dim、dim7, m7 (5), aug、aug7, sus2,
sus4, 7sus4, 4ths, 5ths
1–5
0–63
0–63
SINE, TRI, SQR, SAW
0–63
Explanation
position.
position.
Sets how much the envelope is applied (depth) to the wave
position.
Specifies the pitch in semitone steps
(maximum ±2 octaves).
Specifies the pitch in cents (maximum ±50
cents).
Sets the volume balance for the tones that
make up the chord.
Specifies the chord.
Specifies the chord voicing.
This effect changes the duty ratio of the pulse
width to alter the waveform.
You can use this effect with other waveforms
besides SQR (square wave).
* A value of zero results in a 50:50% duty
ratio.
Sets how much the LFO is applied (depth) to
the PW (pulse width).
The pulse width is modulated according to the
LFO settings.
This sets the waveform.
Distorts the waveform and adds a frequency
component one octave lower than the original
waveform.
Creating a Tone
Explanation
35
