M/S Delay (Mid-Side Delay) - Roland SH-4d Owner's Manual

Parameter Value
0–5
Distortion
0–127
Wf Rate
Wf Depth 0–127
Echo Level 0–127
Direct Lv 0–127
Level 0–127

M/S Delay (Mid-Side Delay)

This effect applies different amounts of delay to left/right signals of similar phase and differing phase.
Parameter
0–127
MD Level
2TAP, 3TAP, 4TAP
MD Mode
MD Tm OFF, ON
Sync
MD. Time 1–1300
MDTime Nt Note(P.167)
-98–+98 [%]
MD
Feedback
200, 250, 315, 400, 500, 630, 800, 1000, 1250,
MD
1600, 2000, 2500, 3150, 4000, 5000, 6300,
HFDamp
8000, BYPASS [Hz]
MD1 Pan L64–63R
MD2 Pan L64–63R
MD3 Pan L64–63R
MD4 Pan L64–63R
0–127
SD Level
2TAP, 3TAP, 4TAP
SD Mode
SD Tm Sync OFF, ON
SD Time 1–1300
SDTime Nt Note(P.167)
-98–+98 [%]
SD
Feedback
200, 250, 315, 400, 500, 630, 800, 1000, 1250,
SD
1600, 2000, 2500, 3150, 4000, 5000, 6300,
HFDamp
8000, BYPASS [Hz]
SD1 Pan L64–63R
SD2 Pan L64–63R
SD3 Pan L64–63R
SD4 Pan L64–63R
Level 0–127
Amount of tape-dependent distortion to be added
This simulates the slight tonal changes that can be detected by signal-analysis
equipment.
Increasing this value will increase the distortion.
Speed of wow/flutter (complex variation in pitch caused by tape wear and rotational
irregularity)
Depth of wow/flutter
Volume of the echo sound
Volume of the original sound
Output Level
Value
Delay volume of left/right input signals whose phase is similar (in
phase)
Delay divisions for the input signals whose left/right phase is
similar (identical phase)
If this is ON, the delay synchronizes with the tempo.
Adjusts the time from the original sound until the delay sound is
heard.
Adjusts the proportion of the delay sound that is fed back into the
effect.
Negative (-) settings will invert the phase.
Adjusts the frequency above which sound fed back to the effect is
filtered out. If you don't want to filter out any high frequencies, set
this parameter to BYPASS.
Panning of the first delay sound
Panning of the second delay sound
Panning of the third delay sound
Panning of the fourth delay sound
Delay volume of left/right input signals whose phase is distant
(opposite phase)
Delay divisions for the input signals whose left/right phase is
distant (reverse phase)
If this is ON, the delay synchronizes with the tempo.
Adjusts the time from the original sound until the delay sound is
heard.
Adjusts the proportion of the delay sound that is fed back into the
effect.
Negative (-) settings will invert the phase.
Adjusts the frequency above which sound fed back to the effect is
filtered out. If you don't want to filter out any high frequencies, set
this parameter to BYPASS.
Panning of the first delay sound
Panning of the second delay sound
Panning of the third delay sound
Panning of the fourth delay sound
Output Level
Explanation
Explanation
