Roland SH-4d Owner's Manual page 166

MFX Parameters
Parameter Value
DS - PH - EN - SP
DS - SP - PH - EN
DS - SP - EN - PH
DS - EN - PH - SP
DS - EN - SP - PH
PH - DS - SP - EN
PH - DS - EN - SP
PH - SP - DS - EN
PH - SP - EN - DS
PH - EN - DS - SP
PH - EN - SP - DS
Seq SP - DS - PH - EN
SP - DS - EN - PH
SP - PH - DS - EN
SP - PH - EN - DS
SP - EN - DS - PH
SP - EN - PH - DS
EN - DS - PH - SP
EN - DS - SP - PH
EN - PH - DS - SP
EN - PH - SP - DS
EN - SP - DS - PH
EN - SP - PH - DS
DS Switch OFF, ON
Sets the type of distortion.
MELLOW DRV
OVERDRIVE
CRY DRV
DS Type
MELLOW DST
LIGHT DST
FAT DIST
FUZZ DIST
DS Drive 0–100
DS Level 0–100
PH Switch OFF, ON
50 [Hz]–15.0
PH Manual
[kHz]
PH Rate 0.1–10.0 [Hz]
PH Depth 0–100
PH 0–100
Resonance
PH Mix 0–100
SP Switch OFF, ON
SP Band Ctrl1 -15–+15 [dB]
SP Band Ctrl2 -15–+15 [dB]
SP Band Ctrl3 -15–+15 [dB]
SP Band Ctrl4 -15–+15 [dB]
SP Band Ctrl5 -15–+15 [dB]
SP Band Ctrl6 -15–+15 [dB]
SP Width 1–5
EH Switch OFF, ON
EH Sens
0–100
0–100
EH Mix
Pan L64–63R
Level 0–127
166
DS: Distortion
PH: Phaser
SP: Spectrum
EN: Enhancer
Turns the distortion on/off.
Softer distortion with a slightly darker sound.
Distortion that resembles a vacuum tube amp being driven.
Distortion that emphasizes the high end.
Gives the feeling of distortion playing through a large amp.
Strong distortion with a bright sound.
Thick distortion that emphasizes the low and high ends.
Distortion that's even more powerful that FAT DIST.
Sets the amount of distortion.
Sets the distortion output level.
Turns the phaser on/off.
Sets the basic frequency from which the sound is modulated with the phaser effect.
Sets the cycle of the phaser modulation.
Sets the depth of the phaser modulation.
Sets the amount of feedback for the phaser. Increasing the value creates a more unusual
sound.
Sets the level of the phase-shifted sound.
Turns the spectrum on/off.
Sets the gain (amount of boost/cut) in the 250 Hz range.
Sets the gain (amount of boost/cut) in the 500 Hz range.
Sets the gain (amount of boost/cut) in the 1000 Hz range.
Sets the gain (amount of boost/cut) in the 2000 Hz range.
Sets the gain (amount of boost/cut) in the 4000 Hz range.
Sets the gain (amount of boost/cut) in the 8000 Hz range.
Sets the bandwidth for changing the levels, common to all bands.
Turns the enhancer on/off.
Sets how easily the enhancer effect is applied.
Sets the ratio at which the harmonics generated by the enhancer are mixed with the original
sound.
Changes the pan.
Sets the output volume.
Explanation
