Ds -> Chorus (Distortion -> Chorus); Ds -> Flanger (Distortion -> Flanger) - Roland SH-4d Owner's Manual

MFX Parameters
DS -> Chorus (Distortion -> Chorus)
Parameter Value
0–127
Dist Drive
Dist Pan L64–63R
Cho 0.0–100 [ms]
PreDly
OFF, ON
Cho Sync
C. Rate 0.05–10.00 [Hz]
C.Rate Nt Note(P.167)
Cho Depth 0–127
D100: 0W–D0:
Cho Bal
100W
Level 0–127
DS -> Flanger (Distortion -> Flanger)
Parameter Value
0–127
Dist Drive
Dist Pan L64–63R
Flg PreDly 0.0–100 [ms]
OFF, ON
Flg Sync
F. Rate 0.05–10.00 [Hz]
F.Rate Nt Note(P.167)
Flg Depth 0–127
150
Degree of distortion
Also changes the volume.
Stereo location of the distortion sound
Adjusts the delay time from the direct sound until the chorus sound is heard.
If this is ON, the rate synchronizes with the tempo of the rhythm.
Tempo (Pattern)
Tempo (System)(P.76)
Frequency of modulation
Depth of modulation
Adjusts the volume balance between the sound that is sent through the chorus (W) and the
sound that is not sent through the chorus (D).
Output Level
Degree of distortion
Also changes the volume.
Stereo location of the distortion sound
Adjusts the delay time from the direct sound until the flanger sound is heard.
If this is ON, the rate synchronizes with the tempo of the rhythm.
Tempo (Pattern)
Tempo (System)(P.76)
Frequency of modulation
Depth of modulation
Explanation
Explanation
