Flanger -> Dly (Flanger -> Delay) - Roland SH-4d Owner's Manual

MFX Parameters
Parameter
C. Rate 0.05–10.00 [Hz]
C.Rate Nt Note(P.167)
Cho Depth 0–127
D100: 0W–D0: 100W
Cho Bal
OFF, ON
Delay
Sync
D. Time 1–2600
D.Time Nt Note(P.167)
-98–+98 [%]
Delay Fbk
200, 250, 315, 400, 500, 630, 800, 1000, 1250,
Dly HF 1600, 2000, 2500, 3150, 4000, 5000, 6300, 8000,
BYPASS [Hz]
D100: 0W–D0: 100W
Dly Bal
Level 0–127
Flanger -> Dly (Flanger -> Delay)
Parameter
0.0–100 [ms]
Flg PreDly
OFF, ON
Flg Sync
F. Rate 0.05–10.00 [Hz]
F.Rate Nt Note(P.167)
Flg Depth 0–127
-98–+98 [%]
Flg Fbk
D100: 0W–D0: 100W
Flg Bal
OFF, ON
Delay
Sync
D. Time 1–2600
D.Time Nt Note(P.167)
-98–+98 [%]
Delay Fbk
200, 250, 315, 400, 500, 630, 800, 1000, 1250,
Dly HF 1600, 2000, 2500, 3150, 4000, 5000, 6300, 8000,
BYPASS [Hz]
164
Value
Value
Explanation
Tempo (System)(P.76)
Frequency of modulation
Depth of modulation
Volume balance between the direct sound (D) and the chorus
sound (W)
If this is ON, the rate synchronizes with the tempo of the rhythm.
Tempo (Pattern)
Tempo (System)(P.76)
Delay time from when the original sound is heard to when the
delay sound is heard
Adjusts the proportion of the delay sound that is fed back into the
effect.
Negative (-) settings will invert the phase.
Adjusts the frequency above which sound fed back to the effect
will be cut. If you do not want to cut the high frequencies, set this
parameter to BYPASS.
Adjusts the volume balance between the sound that is sent
through the delay (W) and the sound that is not sent through the
delay (D).
Output Level
Explanation
Adjusts the delay time from the direct sound until the flanger
sound is heard.
If this is ON, the rate synchronizes with the tempo of the rhythm.
Tempo (Pattern)
Tempo (System)(P.76)
Frequency of modulation
Depth of modulation
Adjusts the proportion of the flanger sound that is fed back into
the effect.
Negative (-) settings will invert the phase.
Volume balance between the direct sound (D) and the flanger
sound (W)
If this is ON, the rate synchronizes with the tempo of the rhythm.
Tempo (Pattern)
Tempo (System)(P.76)
Delay time from when the original sound is heard to when the
delay sound is heard
Adjusts the proportion of the delay sound that is fed back into the
effect.
Negative (-) settings will invert the phase.
Adjusts the frequency above which sound fed back to the effect
will be cut. If you do not want to cut the high frequencies, set this
parameter to BYPASS.
