Roland SH-4d Owner's Manual page 170

PATTERN CHORUS
3Tap PanDly (3Tap Pan Delay)
Delay sound is heard in the three locations you specify.
Parameter Value
Dly Sync OFF, ON
Dly Msec 1–2600
Dly Note Note
-98–+98 [%]
Feedback
200–8000 [Hz],
HF Damp
BYPASS (*1)
Dly1 Pan L64–63R
Dly2 Pan L64–63R
Dly3 Pan L64–63R
Dly1 Level 0–127
Dly2 Level 0–127
JUNO Chorus (JUNO-106 Chorus)
This models the chorus effects of the Roland JUNO-106.
Parameter Value
I, II, I+II, JX I, JX II
Mode
Noise Level 0–127
JV Chorus
Parameter Value
OFF
Filter Type LPF
HPF
200–8000 [Hz]
Cutoff Freq
Pre Delay 0.0–100.0 [ms]
Rate Sync OFF, ON
Rate Hz 0.05–10.00 [Hz]
Rate Note Note
Depth
0–127
Phase 0–180 [deg]
Feedback 0–127
Note 1/64T, 1/64, 1/32T, 1/32, 1/16T, 1/32., 1/16, 1/8T, 1/16., 1/8, 1/4T, 1/8., 1/4, 1/2T, 1/4., 1/2, 1T, 1/2., 1, 2T, 1., 2
(*1) 200, 250, 315, 400, 500, 630, 800, 1000, 1250, 1600, 2000, 2500, 3150, 4000, 5000, 6300, 8000 [Hz], BYPASS
170
If this is ON, the delay synchronizes with the tempo.
Delay time of the third delay sound after the original sound is heard.
Adjusts the proportion of the delay sound that is fed back into the effect. Negative (-) settings
will invert the phase.
Adjusts the frequency above which sound fed back to the effect is filtered out. If you don't want
to filter out any high frequencies, set this parameter to BYPASS.
Adjusts the pan position of Delay 1.
Adjusts the pan position of Delay 2.
Adjusts the pan position of Delay 3.
Adjusts the volume of Delay 1.
Adjusts the volume of Delay 2.
Type of Chorus
I+II: the state where both buttons are pressed at the same time.
Volume of noise
The filter is not used.
This filter cuts off the high frequencies.
This filter cuts off the low frequencies.
Adjusts the center frequency used when the filter cuts a specific frequency region.
Adjusts the delay time from when the direct sound plays until the reverb sound is heard.
When this is ON, the delay synchronizes with the tempo.
Adjusts the frequency of modulation.
Adjusts the depth of modulation.
Adjusts the depth of the chorus sound.
Adjusts how much of the sound that is fed into the chorus is returned to the input.
Explanation
Explanation
Explanation
