Configuring the LFO

1. Hold down the [SHIFT] button and press the [8] button.
The LFO screen appears.
Item Value
OFF, Turn this ON to sync the LFO cycle with the tempo.
Rate Sync
ON
OFF, Sets whether to synchronize the start of the LFO cycle with the timing you use to play the keys ("ON" to
Key Trigger
ON synchronize, "OFF" to disable).
LFO Pan -63– Sets the depth of the LFO when it is applied to the pan setting.
Depth +63
Sets the LFO start phase value when Key Trigger is "ON".
0 1 cycle
Phase
1 1/4 cycle
Position
2 1/2 cycle
3 3/4 cycle
Explanation
