MFX Parameters
Parameter Value
NEWCASE
Bass -50–+50
Treble -50–+50
Flg Switch OFF, ON
Flg PreDly 0.0–100 [ms]
OFF, ON
Flg Sync
F. Rate 0.05–10.00 [Hz]
F.Rate Nt Note(P.167)
Flg Depth 0–127
-98–+98 [%]
Flg Fbk
D100: 0W–D0: 100W
Flg Bal
LINE, OLD, NEW,
Sp Type
WURLY, TWIN
OD Switch OFF, ON
OD Gain 0–127
0–127
OD Drive
Level 0–127
EP -> Phaser (EP Amp Simulator -> Phaser)
Parameter
Type
OLDCASE
NEWCASE
Bass -50–+50
Treble -50–+50
Phs Switch OFF, ON
OFF, ON
Phs Sync
P. Rate 0.05–10.00 [Hz]
P.Rate Nt Note(P.167)
Phs Manual 0–127
Phs Depth
0–127
Phs Reso 0–127
Phs Mix 0–127
LINE, OLD, NEW, WURLY, TWIN
Sp Type
OD Switch OFF, ON
OD Gain 0–127
0–127
OD Drive
Level 0–127
160
A standard electric piano sound of the late 70s and early 80s
Amount of low-frequency boost/cut
Amount of high-frequency boost/cut
Flanger on/off
Adjusts the delay time from the direct sound until the flanger sound is heard.
If this is ON, the rate synchronizes with the tempo of the rhythm.
Tempo (Pattern)
Tempo (System)(P.76)
Frequency of modulation
Depth of modulation
Adjusts the proportion of the flanger sound that is fed back into the effect. Negative (-)
settings will invert the phase.
Adjusts the volume balance between the sound that is sent through the flanger (W) and
the sound that is not sent through the flanger (D).
Type of speaker
If LINE is selected, the sound will not be sent through the speaker simulation.
Overdrive on/off
Overdrive input level
Degree of distortion
Also changes the volume.
Output Level
Value
Type of amp
A standard electric piano sound of the early 70s
A standard electric piano sound of the late 70s and early 80s
Amount of low-frequency boost/cut
Amount of high-frequency boost/cut
Phaser on/off
If this is ON, the rate synchronizes with the tempo of the rhythm.
Tempo (Pattern)
Tempo
Frequency of modulation
Adjusts the basic frequency from which the sound will be modulated.
Depth of modulation
Amount of feedback
Level of the phase-shifted sound
Type of speaker
If LINE is selected, the sound will not be sent through the speaker simulation.
Overdrive on/off
Overdrive input level
Degree of distortion
Also changes the volume.
Output Level
Explanation
Explanation
(System)(P.76)
