Pitch; Pitchshiftr (Pitch Shifter) - Roland SH-4d Owner's Manual

MFX Parameters

Pitch

PitchShiftr (Pitch Shifter)

A stereo pitch shifter.
Parameter Value
Coarse -24–+12 [sem]
Fine -100–+100
OFF, ON
Delay Sync
D. Time 1–1300
D.Time Nt Note(P.167)
-98–+98 [%]
Feedback
Low Gain -15–+15 [dB]
-15–+15 [dB]
High Gain
Balance D100: 0W–D0: 100W
Level 0–127
146
Adjusts the pitch of the pitch shifted sound in semitone steps.
Adjusts the pitch of the pitch shifted sound in 2-cent steps.
If this is ON, the rate synchronizes with the tempo of the rhythm.
Tempo (Pattern)
Tempo (System)(P.76)
Adjusts the delay time from the direct sound until the pitch shifted sound is heard.
Adjusts the proportion of the pitch shifted sound that is fed back into the effect.
Negative (-) settings will invert the phase.
Amount of boost/cut for the low-frequency range
Amount of boost/cut for the high-frequency range
Volume balance between the direct sound (D) and the pitch shifted sound (W)
Output Level
Explanation
