Roland SH-4d Owner's Manual page 172

PATTERN DELAY
Parameter Value
This sets how the panning changes.
TRI
SQR
Trm
SIN
ModWave
SAW1
SAW2
TRP
Trm Sync OFF, ON
Trm Hz 0.05–10.00 [Hz]
Trm Note Note
Trm Depth 0–127
2Tap PanDly (2Tap Pan Delay)
Delay sound is heard in the two locations you specify.
Parameter Value
Dly Sync OFF, ON
Dly Msec
1–1300
Dly Note Note
-98–+98 [%]
Feedback
200–8000 [Hz],
HF Damp
BYPASS (*1)
Dly1 Pan L64–63R
Dly2 Pan L64–63R
Dly1 Level 0–127
Dly2 Level 0–127
3Tap PanDly (3Tap Pan Delay)
Delay sound is heard in the three locations you specify.
Parameter Value
Dly Sync OFF, ON
Dly Msec 1–2600
Dly Note Note
-98–+98 [%]
Feedback
200–8000 [Hz],
HF Damp
BYPASS (*1)
Dly1 Pan L64–63R
Dly2 Pan L64–63R
Dly3 Pan L64–63R
Dly1 Level 0–127
Dly2 Level 0–127
Dly3 Level 0–127
Note 1/64T, 1/64, 1/32T, 1/32, 1/16T, 1/32., 1/16, 1/8T, 1/16., 1/8, 1/4T, 1/8., 1/4, 1/2T, 1/4., 1/2, 1T, 1/2., 1, 2T, 1., 2
(*1) 200, 250, 315, 400, 500, 630, 800, 1000, 1250, 1600, 2000, 2500, 3150, 4000, 5000, 6300, 8000 [Hz], BYPASS
172
Triangle wave
Square wave
Sine wave
Sawtooth wave
Trapezoidal wave
If this is on, the tremolo synchronizes with the tempo.
Adjusts the rate of the tremolo.
Adjusts the depth of the tremolo.
If this is ON, the delay synchronizes with the tempo.
Adjusts the time until the second delay sound is heard.
Adjusts the proportion of the delay sound that is fed back into the effect. Negative (-) settings
will invert the phase.
Adjusts the frequency above which sound fed back to the effect is filtered out. If you don't want
to filter out any high frequencies, set this parameter to BYPASS.
Adjusts the pan position of Delay 1.
Adjusts the pan position of Delay 2.
Adjusts the volume of Delay 1.
Adjusts the volume of Delay 2.
If this is ON, the delay synchronizes with the tempo.
Delay time of the third delay sound after the original sound is heard.
Adjusts the proportion of the delay sound that is fed back into the effect. Negative (-) settings
will invert the phase.
Adjusts the frequency above which sound fed back to the effect is filtered out. If you don't want
to filter out any high frequencies, set this parameter to BYPASS.
Adjusts the pan position of Delay 1.
Adjusts the pan position of Delay 2.
Adjusts the pan position of Delay 3.
Adjusts the volume of Delay 1.
Adjusts the volume of Delay 2.
Adjusts the volume of delay 3.
