5.5
Location
For professional installation, safe operation and barrier-free access to the charging system, the
following points must be observed when selecting the location.
•
National or local regulations.
•
Do not install the charging system in the hazard areas of:
–
Flammable, combustible and explosive materials
–
Running or jet water
•
Do not install the charging system in the following areas:
–
Areas that are potentially explosive (e.g. gas filling stations)
–
Areas where backwater or storm water is to be expected
–
Areas where flooding is to be expected
–
Areas where heat domes or heat accumulation can occur
•
The substrate must have sufficient strength and load-bearing capacity to withstand the
mechanical loads.
•
Provide sufficient space to maintain the minimum distances:
–
Approx. 120 cm between two charging systems
•
Ensure a sufficient fresh air supply for cooling the charging system and heat dissipation.
•
Observe ambient conditions, see also chapter 3.3 Technical specifications, page 16.
ATTENTION
Damage to the unit
Vehicles unintentionally running into the unit can cause damage.
•
Select the installation site in such a way that damage due to vehicles unintentionally running
into the unit is prevented.
•
If damage cannot be ruled out, suitable protective measures must be taken.
2022-11
A01Axxxxxx.xx | 04
27
