9.1.23 DclnsulationCodeFault (Z)

Name
Area
Description
Reported by:
Handling
Indication on display
Action

9.1.24 DclnsulationCodelnvalid (1)

Name
Area
Description
Reported by:
Handling
Indication on display
Action

9.1.25 DclnsulationTestFailureOnStart (2)

Name
Area
Description
Reported by:
Handling
Indication on display
Action
2022-11
DclnsulationCodeFault
Connector (DC)
An insulation error has occurred during a DC charging process.
Connector
• The charging process is aborted
• The error is shown on the display
Z
Switch the complete charging system off and on again. Notify customer
service if the error persists.
DclnsulationCodelnvalid
Connector (DC)
An invalid insulation status has occurred during a DC charging process.
Connector
• The charging process is aborted
• The error is shown on the display
1
Switch the complete charging system off and on again. Notify customer
service if the error persists.
DclnsulationTestFailureOnStart
Connector (DC)
The insulation test at the start of the charging process has found an error.
Connector
• The charging process is aborted
• The error is shown on the display
2
Switch the complete charging system off and on again. Notify customer
service if the error persists.
