7�3�7�1� Transformation ratios�
Configuration variable
Voltage primary
Voltage secondary
Current primary
Current secondary
Voltage ratio x Current ratio ≤ 300000.
(5)
Voltage ratio ≤ 1000.
Configurable parameter in the models: CVM-E3-MINI-ITF, CVM-E3-MINI-ITF-WiEth, CVM-E3-MINI-MC and
(6)
CVM-E3-MINI-MC-WiEth.
Configurable parameter in the models: CVM-E3-MINI-ITF and CVM-E3-MINI-ITF-WiEth.
(7)
Note: The ratio is between the primary and the secondary.
Note: The 5 registers must be written or read at once (as a group); otherwise. the system will
respond with an error.
7�3�7�2� Flex sensor type (Models CVM-E3-MINI-FLEX and CVM-E3-MINI-FLEX-WiEth)
Flex sensor
7�3�7�3� Number of quadrants
Number of quadrants
7�3�7�4� Measurement convention
Configuration variable
Measurement convention
94
Table 37: Modbus memory map: Transformation ratios�
(5)
(6)
(7)
Table 38: Modbus memory map: Flex sensor type�
Configuration variable
Table 39: Modbus memory map: Number of quadrants
Configuration variable
Table 40: Modbus memory map: Measurement convention�
Transformation ratios
Address Valid data margin
2710 - 2711
2712
2713
2714
Tipo de sensor Flex
Address Valid data margin
0: 100 uV/A
2756
1: 76 uV/A
Numberof quadrants
Address Valid data margin
0: 4 quadrants
2B64
1: 2 quadrants
Measurement convention
Address Valid data margin
0: Circutor
2B86
Default value
1 - 599999
1 - 999
1 - 10000
0: .../1A
1: ../5 A
Default value
0
Default value
Default value
1: IEC
2: IEEE
Instruction Manual
CVM-E3-MINI
1
1
5
1
0
0
