6�18�1� MAXIMUM VALUE
This screen is used to programme the maximum value, i.e., the value above which the alarm
will be activated.
Press the
of the screen.
Press the
Note: The device allows the user to configure negative values. To do so, increase the first digit
to a value higher than 9.
When the desired value is shown on the screen, use the
cursor.
Note: Pay special attention when programming the Generation Power (displayed with
negative values).
Example: If you wish to enter a generation power alarm with limits between 2 kW and 1 kW,
program the following as the maximum value : - 1 kW and the following as the minimum
value : - 2 kW.
To validate the value, press the
Press key
6�18�2� MINIMUM VALUE
This screen is used to programme the minimum value, i.e., the value under which the alarm
will be activated.
Press the
of the screen.
Press the
Note: The device allows the user to configure negative values. To do so, increase the first digit
to a value higher than 9.
68
key for 3 seconds to enter the edit mode. The prog icon will flash on the left
key to modify the value of the flashing digit.
to access the next programming step.
key for 3 seconds to enter the edit mode. The prog icon will flash on the left
key to modify the value of the flashing digit.
key for 3 seconds; the prog icon will stop flashing.
CVM-E3-MINI
and keys to move the edit
Instruction Manual
