PROFILE

3
The installation's consumed and generated energy are displayed on the e
The installation status is also displayed:
Installation is consuming energy.
Installation is generating energy.
Long press (3 sec.) the
values displayed.
The generation values are identified with the negative sign on the screen, which appears in
front of each parameter.
Note : If the 2 quadrant option has been configured, only the consumed values can be
displayed.
This profile is identified with the e
Use keys and to browse the different screens (short keystroke).
Screen
Instruction Manual
or keys to jump from the generated values to the consumed
symbol on the left of the screen.
3
Table 19: Screens of the e
Total three-phase active Energy
Total three-phase Apparent Energy
Total three-phase Inductive Reactive Energy
profile of the device.
3
profile.
3
Parameters (units)
(2) (3)
(2)(3)
(kvar h)
L
(kWh)
(kVAh)
(2)(3)
