CVM-E3-MINI
Instruction Manual
Table 18 (Continuation): Analyzer profile screens�
Screen
Parameters (units)
Current L1 (A)
Current L2 (A)
Current L3 (A)
Active Power L1 (M/kW)
Active Power L2 (M/kW)
Active Power L3 (M/kW)
Apparent Power L1 (M/kVA)
Apparent Power L2 (M/kVA)
Apparent Power L3 (M/kVA)
Inductive Reactive Power L1 (M/kvar
Inductive Reactive Power L2 (M/kvar
Inductive Reactive Power L3 (M/kvar
Capacitive Reactive Power L1 (M/kvar
Capacitive Reactive Power L2 (M/kvar
Capacitive Reactive Power L3 (M/kvar
Active Power III (M/kW)
Apparent Power III (M/kVA)
Inductive Reactive Power III (M/kvar
)
L
)
L
)
L
)
C
)
C
)
C
)
L
41
