Table 33 (Continuation): Modbus memory map: Deleting parameters�
Deleting three-phase energies
Deleting energies per phase (L1, L2, L3)
Deleting energies per phase (L1)
Deleting energies per phase (L2)
Deleting energies per phase (L3)
Deleting all of the previous parameters
7�3�5� POWER STATUS
All the Modbus map addresses are hexadecimal.
The function 0x04 is implemented for this variable.
This variable indicates the quadrant in which the device is operating.
Power status
Power status
The variable format is shown in
Bit 7 Bit 6 Bit 5
0 0
7�3�6� DETECTION OF INCORRECT DIRECTION OF ROTATION
All the Modbus map addresses are hexadecimal.
The function 0x04 is implemented for this variable.
This variable indicates whether an incorrect direction of rotation has been detected in the
voltages.
Table 36: Modbus memory map: Detection of incorrect direction of rotation�
Detection of incorrect direction of rotation
Variable
Detection of incorrect direction of rotation
7�3�7� DEVICE CONFIGURATION VARIABLES�
All the Modbus map addresses are hexadecimal.
The functions 0x04 and 0x10 are implemented for this variable.
The device's Modbus function does not check whether the variables recorded are within the
correct margins, they are only checked when they are read from the EEPROM. So if any
parameter is recorded with an incorrect value the device will be configured with its default value.
The Modbus configuration will not take effect until the device is reset.
Instruction Manual
Parameters
Table 34: Modbus memory map: Power status
Variable
Table 35:
Table 35: Variable format: Power status�
Bit 4 Bit 3
0 0 1: Capacitive
Address
834
873
870
871
872
898
Address Default value
7D1
Bit 2 Bit 1
1: Inductive 1: Generated
Address
0: No fault has been detected
7D5
1: Fault detected
Valid data margin
FF00
FF00
FF00
FF00
FF00
FF00
-
Bit 0
1: Consumed
Value
93
