Circutor CVM-E3-MINI-ITF Instruction Manual page 96

7�3�7�10� Cost of energy consumption and generation�
Cost per kWh of tariff 1 consumption
Cost per kWh of tariff 2 consumption
Cost per kWh of tariff 1 generation
Cost per kWh of tariff 2 generation
They have 1 decimal place.
(10)
7�3�7�11� Programming Digital Output T1
Note: The CVM-E3-MINI-xxx-WiEth models do not have a Digital Output, so the alarm only
triggers the activation of the ALARM / ENERGY PULSES LED.
Maximum value
Minimum value
Variable code
Connection delay
Hysteresis
Latch
Disconnection delay
Contacts status
Kilowatts per impulse
Variable code
Pulse width
7�3�7�12� Digital inputs (Models CVM-E3-MINI-xxx)
Operating mode
We can also read the status of the digital inputs when they are in logic mode:
The Function 0x04 is implemented for this variable.
96
Table 46: Modbus memory map: Cost of energy consumption and generation�
Configuration variable
(10)
Table 47: Modbus memory map: Programming Digital Output T1 (Alarm)
Programming Digital Output : Alarm
Configuration variable
Table 48: Modbus memory map: Programming Digital Output T1 (pulses output)
Programming Digital Output : Pulses output
Configuration variable
Table 49: Modbus memory map: Configuration of digital inputs.
Configuration variable
Cost per kWh
Address
272C
272D
2730
2731
Address Valid data margin
2AF8-2AF9 depending on the variable
2AFA-2AFB depending on the variable
2AFC Table 20 and Table 21
0 - 9999 seconds
2AFD
2AFE 0 - 99 %
2AFF
1: Yes
2B00 0 - 9999 seconds
0 : Normally open
2B01
1: Normally closed
Address Valid data margin
2B20-2B21 0.001 - 999.99 kWh
2AFC Table 22
2B22 30 - 500 ms
Address Valid data margin
2B66
1: Logic state
Valid data margin
0 - 1�9999
0 - 1�9999
0 - 1�9999
0 - 1�9999
Default value
0 : No
Default value
1.00 kWh
100 ms
Default value
0: Tariff
Instruction Manual
CVM-E3-MINI
Default
value
0
0
0
0
0
0
0
0
0
0
0
0
0
0
