6�22�1�- MODBUS PROTOCOL: BAUD RATE
The baud rate of modbus communications is programmed on this screen.
Press the
of the screen.
Press key
To validate the value, press the
Press key
6�22�2�- MODBUS PROTOCOL: PERIPHERAL NUMBER
The peripheral number is programmed on this screen.
Press the
of the screen.
Press the
When the desired value is shown on the screen, use the
cursor.
Maximum programming value: 255.
Minimum programming value: 1.
To validate the value, press the
If the value entered by the user is out of the range of programming values, the programmed
value will be deleted and the system will restore it to the last saved value.
76
key for 3 seconds to enter the edit mode. The prog icon will flash on the left
to browse the options: 9600, 19200, 38400 or 57600 bps.
to access the next programming step.
key for 3 seconds to enter the edit mode. The prog icon will flash on the left
key to modify the value of the flashing digit.
key for 3 seconds; the prog icon will stop flashing.
key for 3 seconds; the prog icon will stop flashing.
