CVM-E3-MINI
5�1�1�- MAXIMUM VALUES
To see the maximum values of the screen being displayed, press the
These are displayed for 10 seconds.
Press the and
The max symbol is shown on the display.
The maximum and minimum values are reset on the programming menu.(
MAXIMUM AND MINIMUM VALUES"
5�1�2�- MINIMUM VALUES
To see the minimum values of the screen being displayed, press the
These are displayed for 30 seconds.
Press the and . keys to display all other maximum values.
The min symbol is shown on the display.
The maximum and minimum values are reset on the programming menu. (
MAXIMUM AND MINIMUM VALUES"
5�1�3�- MAXIMUM DEMAND
The device calculates the maximum demand of the following:
The Current of each phase.
Three-Phase Active Power.
Three-Phase Apparent Power.
Three-Phase inductive Power.
 Three-Phase capacitive Power.
This value can be displayed on the display screen of the parameter by pressing the
keys at the same time.
The dem symbol appears on the display.
Press keys or to stop displaying the maximum demand values.
The maximum demand values are reset on the programming menu:
MUM DEMAND"
5�1�4�- HARMONICS
The device can display the voltage and current harmonics, up to the 31st order harmonic, for
each one of the lines, L1, L2 and L3.
Harmonics display is disabled by defect; see
to enable display.
A minimum signal level is required to measure harmonics correctly, i.e., a signal level of at least
Instruction Manual
keys to display all other maximum values.
)
)
"6.13.- ENABLE HARMONICS DISPLAY SCREEN"
key for 2 seconds.
"6.10.- DELETING
key for 2 seconds.
"6.10.- DELETING
and
"6.10.- DELETING MAXI-
43
