4.4.- LED INDICATORS
The CVM-E3-MINI device has 2 LEDs:
- CPU, indicates that the device is on, flashing each second.
- ALARM / ENERGY PULSES; if this is on, it indicates that an alarm or an energy pulses
output has been activated. In the case of the energy pulses, the LED will be lit and flash
with the rate of these pulses.
4.5.- DIGITAL INPUT (Models CVM-E3-MINI-xxx)
The CVM-E3-MINI-xxx has one digital input (terminals S and 9 on
grammed to operate as a logic or tariff selection input.
If configured as a logic input, the device displays the status of that input. See
MODE OF DIGITAL INPUT"
Press the
AND OUTPUT STATUS SCREEN"
The selected tariff can be determined in accordance with the status of the inputs, as shown in
.
Table 17
Note: In the CVM-E3-MINI-xxx-WiEth models, the tariff is selected in the settings menu.
38
CPU
Figure 27: LED Indicators of the CVM-E3-MINI�
keys to access the digital input status screen, see
Table 17: Selecting the tariff in accordance with the input status.
IN1, Input 1
Logic input
x
ALARM / ENERGY PULSES
Tariff
Tariff selection
T1
0 T1
1 T2
CVM-E3-MINI
) that can be pro-
Figure 4
"6.19. OPERATING
"5.4.- DIGITAL INPUT
Instruction Manual
