6�18�8� KILOWATTS PER PULSE
Note: This screen is displayed if the alarm parameter has been selected from an energy value,
see
Table 22
This screen is used to programme the kilowatts per pulse.
Press the
of the screen.
Press the
When the desired value is shown on the screen, use the
cursor.
Maximum programming value: 999.99 kWh
Minimum programming value: 000.01 kWh
To validate the value, press the
If the value entered by the user is out of the range of programming values, the programmed
value will be deleted and the system will restore it to the last saved value.
Press key
6�18�9� PULSE WIDTH
Note: This screen is displayed if the alarm parameter has been selected from an energy value,
see
Table 22
The width of the pulse is selected on this screen in ms.
Press the
of the screen.
Press the
72
.
key for 3 seconds to enter the edit mode. The prog icon will flash on the left
key to modify the value of the flashing digit.
to access the next programming step.
.
key for 3 seconds to enter the edit mode. The prog icon will flash on the left
key to modify the value of the flashing digit.
key for 3 seconds; the prog icon will stop flashing.
CVM-E3-MINI
and keys to move the edit
