CVM-E3-MINI
6�22�7�- BACnet PROTOCOL : ID
The device ID is programmed on this screen.
key for 3 seconds to enter the edit mode. The prog icon will flash on the left
Press the
of the screen.
Press the key to modify the value of the flashing digit.
When the desired value is shown on the screen, use the
cursor.
Maximum programming value: 99999.
Minimum programming value: 0.
To validate the value, press the
If the value entered by the user is out of the range of programming values, the programmed
value will be deleted and the system will restore it to the last saved value.
Press key to access the next programming step.
6�22�8�- BACnet PROTOCOL : MAC ADDRESS
The MAC address is programmed on this screen.
Press the key for 3 seconds to enter the edit mode. The prog icon will flash on the left
of the screen.
Press the key to modify the value of the flashing digit.
When the desired value is shown on the screen, use the
cursor.
Maximum programming value: 127.
Instruction Manual
key for 3 seconds; the prog icon will stop flashing.
and keys to move the edit
and keys to move the edit
79
