CVM-E3-MINI
3.4.- CVM-E3-MINI-FLEX: ROGOWSKI SENSORS
The CVM-E3-MINI-FLEX model measures currents using flexible sensors, based on the Ro-
gowski coil principle.
The flexibility of the sensor allows it to measure an alternating current irrespective of the posi-
tion of the conductor.
CIRCUTOR has 1 Rogowski sensor model that can be used with the CVM-E3-MINI-FLEX:
FLEX-MAG�
shows the connection of the sensors and
Table 6
Note: For more information, consult the corresponding sensor guide.
Instruction Manual
Table 5
Table 5: Position error�
Position
A
B
A
B
Table 6: Probe cable terminal connections
Probe cable terminal connections
FLEX-MAG
Black : Shield (SHLD)
Blue: Common (C)
Green: Measuring channel (L1, L2, L3, N)
the maximum position error.
Error
± 1%
A ± 3%
Shield
Común / Common
Canal de medida / Measuring channel
