Section 1
5 - 4
Service Tools (continued)
SECTION E - HYDRAULICS
Ram Dismantling and Assembly
Ram Piston Head Nut (Rig Assembly - Section E, page 75 - 10)
Item Part Number
1 993/99525
2 993/99522
3 993/99523
4 993/99524
5 556/43400
6 545/18000
7 811/50232
Spanner Requirements
JS200/JS200LC/JS220/JS220LC
993/99518 Bucket ram
SSP0047 Boom ram
993/99519 Dipper ram
JS240/JS240LC/JS260/JS260LC
993/99519 Bucket ram
993/99519 Boom ram
993/99521 Dipper ram
Note: All spanners have operating centres of 500 mm.
9803/6400
General Information
Description
Rig assembly (not including spanners and ram)
Anchor side plate (supplied loose unwelded)
Anchor cross member (supplied loose unwelded)
Ram eye end modification
Lift ram
Lynch pin
1
1 / in Pivot pin
4
90 mm A/F Nut
95 mm A/F Nut
100 mm A/F Nut
100 mm A/F Nut
100 mm A/F Nut
115 mm A/F Nut
Section 1
5 - 4
Quantity
1
1
1
1
1
1
1
Issue 1
