Display Monitor (continued)
Warning Display (Message Display)
START
Warning
NO
Note 1: If several instructions are displayed they appear alternately every 5 seconds.
Note 2: When AUTO GLOW warm-up is finished, buzzer is sounded for 3 seconds.
! Engine emergency stop
! Refuel
! Refill coolant
! Replenish battery fluid
! Air cleaner clogged
! Engine oil pressure down
! Engine filter clogged
! Over heat
! Battery Charging Deficient
! Electric system abnormality
9803/6400
Pump Control
! Overheat
! Electric system abnormality
! Refuel
! Refill coolant
! Engine emergency stop
YES
Idling
Free swing
Engine warm up
Engine emergency stop (emergency stop switch "ON") is displayed.
Fuel amount indicated if low. Check, and supply fuel.
Coolant level is low. Check and supply cooling water.
Battery liquid level sensor is not fitted. Fault should not be displayed.
Air cleaner element is clogged. Wash or replace element.
Pressure of engine oil low. Check engine oil quantity, and replenish if low.
Engine oil filter is clogged. Replace engine oil filter. (When replacing engine oil filter,
also replace engine oil).
Engine coolant or hydraulic oil temperature is high. Turn engine to low idling, to lower the
water or oil temperature.
(Check radiator, and clean it.)
Abnormal charging system is displayed. Check the electric circuit.
Abnormal electric system (short and disconnection) is displayed. Check the electric
circuit.
Electrics
Message Display
Key SW ON
H: Heavy mode
S: Standard mode
L: Light mode
F: Fine mode
Section C
Key SW ON & Engine Running
! Battery charging Deficient
! Engine oil pressure down
! Air cleaner clogged
! Engine filter clogged
!Replenish battery fluid
Auto warm-up
One-touch digging force up
