Section J
8 - 1
Wear Limits
Item
Dimension
Width
Diameter
Diameter
Diameter
Centres
9803/6400
Track and Running Gear
Machine
a
JS200
JS240
b
JS200
JS240
c
JS200
JS240
d
JS200
JS240
e
JS200
JS240
Drive Sprocket
Standard Size
mm
in
66
2.59
582.5
22.93
659
25.9
644.6
25.37
190
7.4
Service Limit
mm
in
60
2.59
576.5
22.69
65.3
25.7
*
Section J
8 - 1
Action
Renew
Renew
Renew
Renew
Renew
Issue 2*
