Section C
8 - 8
Self Test Function (continued)
*
*
When the desired AUTOMATIC IDLE TIME is reached, press
and hold the RESET switch for 20 seconds to enter the
setting into the controller. A buzzer will sound when the
setting is complete.
*
Turn the starter switch to OFF to silence the buzzer.
*
Other functions
*
Other functions, not applicable in normal use, can be
displayed using the SELECT button:
CH:1 = Min engine RPM for scrap magnet use.
*
CH:7 = Changing Proportional Solenoid mA Value.
*
If kerosene fuel is to be used it is necessary to reduce
the current at the proportional solenoid on the hydraulic
pump as follows:
1. Switch ignition on.
2. Press CHANGE button once.
3. Press PATTERN button once.
4. Press SELECT button repeatedly until monitor reads
CH:7
5. Press H MODE switch to change mA value.
(0=normal,1= reduced current).
6. Press RESET button for 20 sec until buzzer sounds.
7. Switch ignition off.
The proportional solenoid mA value is now reduced.
CH:8 = Battery level sensor.
9803/6400
Electrics
Self Test
Message
EA: B ( RPM )
WORK MODE
MODE
CLOCK
Section C
20 Seconds
Self-check
Reset
8 - 8
Issue 2*
