Self Test Function (continued)
*
Start engine. Pressing SELECT changes the display as shown.
*
This monitors pressure switch information in the clock display.
0 1
Excavating
Pressure switch
When the CHANGE switch is pressed when the checks are
completed and the system will return to the STANDARD
MODE for normal operation.
Note: Engine has to be started to perform the above
procedure.
Select boom down, display should be:
*
Select slew left or right, display should be:
Select any other excavator service,
display should be:
Select travel, display should be:
*
Select hammer, display should be:
9803/6400
Electrics
*
Self Test
0 =Switch open
1 =Switch closed
*
Travel/boom/slew/hammer
Pressure switch
1 1
1 1
1 0
0 1
0 1
PRESSURE SWITCH INPUT
Message
CH : PS
WORK MODE
Self-check
MODE
Select
CLOCK
Message
S : STANDARD MODE
WORK MODE
Self-check
Change
MODE
CLOCK
