1.4 Symbols

Attention! Observe the warnings and safety precautions in the accompanying documents.
ESD-sensitive components.
Live electrical components.
Warning of dangerous electrical voltage.
Recycling. Used batteries must be recycled or disposed of in accordance with the relevant national and environmen-
tal regulations.
Separate collection of electric and electronic devices in accordance with Directive 2002/96/EC: Do not dispose of the
device with normal domestic waste. Keep separate from domestic waste and dispose of in an environmentally safe
way in compliance with local regulations.
Follow the Instructions for Use!

1.5 Software Symbols

Symbol name
[Confirm]
[Reject]
[Deactivated]
[Activated]
[Locked]
[Not locked]
[Startup screen]
[Menu]
Description
To confirm, touch the button.
The CARDIOHELP uses the new, changed settings.
To reject, touch the button.
This enables you to reject inputs or changes. The CARDIOHELP uses the previous, unal-
tered settings.
The adjustment is not selected.
The adjustment is selected.
The controls on the display cannot be used. To be able to use the CARDIOHELP, the lock
must be removed.
The controls on the display can be used.
The controls on the display can be used.
The controls on the display can be used.
