3 Check the cover of the rotary knob to see if it matches the existing license.
4 Select an application and touch the
u Rotary knob cover matches license - passed/failed.
Software Version
1 Touch the [Menu] symbol.
2 Touch the [Settings]
3 Select the [System information]
▶ The [System information]
4 Make a note of the software version in the service protocol.
u
Software version __________
Battery Test
1 Remove the power supply cord.
▶ Status bar flashes yellow and displays a message.
▶ Acoustic alarm.
▶ The [Power supply status]
operation] to [external power supply
▶ Alarm can be switched off with symbol
u
Battery switching - passed/failed.
2 Touch the [Power supply status
▶ Status bar without alarm situation and the message
from mains to battery]
[Confirm]
symbol.
menu.
screen is displayed.
symbol changes from
disconnected].
[Current alarm
symbol].
disappears.
