2 System Components
2.7 Bubble Sensor
The separate bubble sensor is for venous bubble monitoring.
Bubble sensor
2.8 Venous Probe
The venous probe of the CARDIOHELP-i (serial number greater than 90420390) measures the venous
blood parameters S
Venous probe
2.9 External Sensors
Temperature sensor "TPO-D L1.8"
Temperature sensor
Pressure sensor set "MTK 960 LogiCal"
Pressure sensors
Service Manual | 3.3 | EN | 05
Copyright Maquet Cardiopulmonary GmbH
| CARDIOHELP System |
O
, Hb, Hct and T
V
2
1
Cover
2
Tube retainer
3
Locking device
4
"CARDIOHELP" connection
.
Ven
1
LEDs
2
Optical sensors
3
Infrared sensor
1
CARDIOHELP connection cable
2
Lock
3
Temperature sensor
1
Pressure dome mounting plate
2
Pressure sensor
3
CARDIOHELP connection cable
4
Pressure dome
