Self-test:
Warning buzzer 2 does not generate an
alarm
Self-test:
Speaker does not generate an alarm
PC-aided function test
Alarm chain not passed
PC-aided function test
LEDs and/or buttons do not function
PC-aided function test
Rotary knob is non-functional
PC-aided function test
Night mode
USB data exchange is not possible.
Data exchange via the Ethernet interface
is not possible.
Data exchange via the ECG interface is
not possible.
The message no batteries available is dis-
played although batteries are inserted.
Zero flow mode cannot be activated.
No or insufficient blood flow
Warning buzzer 2 defective
Volume setting too quiet
Speaker defective
Program error or transmission error
LEDs and/or buttons are defective
Program error or transmission error
Rotary encoder is defective
Program error or transmission error
Program error or transmission error
USB stick is not plugged in.
USB stick not formatted with FAT/
FAT32.
USB stick has insufficient storage
capacity.
Speed is not at 0 RPM.
CARDIOHELP does not have a valid
CARDIOHELP-i license
USB data exchange fails (Internal
USB interface is defective).
USB stick is not compatible.
Ethernet connection is nonfunctional. -
ECG connection is nonfunctional.
Connection between the battery PCB
and the sensor PCB is defective.
Sensor PCB defective.
Battery PCB defective.
"Zero flow mode" button defective
Inconsistent software versions
| CARDIOHELP System | 8 Error Diagnosis
Replace the sensor panel (kit) (⇨ "Replac-
ing the Sensor Panel (Set)", page 111).
Check the volume settings, see Instruc-
tions for Use "Changing Brightness/Vol-
ume"
Contact MCP-HTSC.
Contact MCP-HTSC.
Contact MCP-HTSC.
Contact MCP-HTSC.
Contact MCP-HTSC.
Contact MCP-HTSC.
Contact MCP-HTSC.
Insert the USB stick.
Use the USB stick recommended by MA-
QUET.
Use a different USB stick or delete the
data.
Turn the speed to 0 RPM.
Inform the customer that a CARDIOHELP-
i license is required for this.
Switch the CARDIOHELP off and on. Try
the data exchange once more.
Contact MCP-HTSC.
Use the USB stick recommended by MA-
QUET.
-
Check the connection between the battery
PCB and the sensor PCB.
Check the sensor PCB.
Check the battery PCB.
Contact MCP-HTSC.
The controls foil must be exchanged. Con-
tact MCP-HTSC.
Check the software versions (⇨ "Validate
the Software", page 80).
