Getinge MAQUET CARDIOHELP Service Manual page 88

| 88 | 5 Service Interfaces | CARDIOHELP System |
▶ This may take some time, depending on the amount of events.
▶ The message "Events saved" is displayed.
4 Click on the
5 Select the events according to your requirements (⇨ "Selecting Events", page 89).
Open Events
1 Click on the
2 Click on the
3 Select the desired file and click on the
▶ C:/mydocuments/MAQUET/CARDIOHELPServiceTool/ PoolReadout/...
▶ The events are displayed.
4 Select the events according to your requirements (⇨ "Selecting Events", page 89).
Service Manual | 3.3 | EN | 05
Copyright Maquet Cardiopulmonary GmbH
[OK] button.
[Open event] button.
[Open] button.
[Open] button.
"Events saved" message
[Open event] symbol
"Events" screen
