Identify Disabled Components
Component Names Displayed by Diagnostic
Software
Use the information in this table to identify the name of a component that requires service.
Component
Battery
DIMMs on motherboard
DIMMs on memory risers
Drive backplane
Drives
eUSB drive
Fan modules
Memory risers
Motherboard
PCIe cards
26 SPARC T8-1 Server Service Manual • January 2022
Oracle ILOM Target
/SYS/MB/BAT
/SYS/MB/CM/CMP/BOBn/CHn/DIMM
/SYS/MB/CM/CMP/MRn/BOBn/CHn/DIMM
/SYS/DBP
/SYS/DBP/HDD0 (lower left)
/SYS/DBP/HDD1
/SYS/DBP/HDD2 or /SYS/DBP/NVME0
/SYS/DBP/HDD3 or /SYS/DBP/NVME1
/SYS/DBP/HDD4 or /SYS/DBP/NVME2
/SYS/DBP/HDD5 or /SYS/DBP/NVME3
/SYS/DBP/HDD6
/SYS/DBP/HDD7 (right)
/SYS/MB/EUSB_DISK
As viewed from front of server:
/SYS/MB/FM0 (left)
/SYS/MB/FM1
/SYS/MB/FM2
/SYS/MB/FM3 (right)
/SYS/MB/CM/CMP/MR0
/SYS/MB/CM/CMP/MR1
/SYS/MB
/SYS/MB/PCIE1
/SYS/MB/PCIE2
Links
"Servicing the Battery" on page 117
"Servicing Memory Risers and
DIMMs" on page 83
"Servicing Memory Risers and
DIMMs" on page 83
"Servicing the Drive
Backplane" on page 147
"Servicing Drives" on page 59
"Servicing Fan
Modules" on page 69
"Servicing Memory Risers and
DIMMs" on page 83
"Servicing the
Motherboard" on page 129
"Servicing PCIe
Cards" on page 107
