Extend the Server to the Service Position
Note -
service position.
1.
Verify that no cables will be damaged or will interfere when the server is
extended.
Although the CMA that is supplied with the server is hinged to accommodate extending the
server, you should ensure that all cables and cords are capable of extending.
2.
From the front of the server, release the two slide release latches.
Squeeze the green slide release latches to release the slide rails.
3.
While squeezing the slide release latches, slowly pull the server forward until the
slide rails latch.
Related Information
"Release the CMA" on page 51
■
"Remove the Server From the Rack" on page 52
■
50
SPARC T8-1 Server Service Manual • January 2022
You can replace the drives and rear power supplies without extending the server into the
