Internal Component Locations
No. Component
6 Memory risers
7 DIMMs on memory risers
8 DIMMs on motherboard
9 PCIe cards
10 Battery
11 SPM
12 Power supplies
13 Motherboard
14 Chassis
15 Drives
Processor chip (replaceable only by
replacing the motherboard)
eUSB drive
16 SPARC T8-1 Server Service Manual • January 2022
Oracle ILOM Target
/SYS/MB/CM/CMP/MR0
/SYS/MB/CM/CMP/MR1
/SYS/MB/CM/CMP/MR[0-1]/BOB[0-3]1/
CH[0-1]/DIMM
/SYS/MB/CM/CMP/BOB[0-3]0/CH[0-1]/
DIMM
/SYS/MB/PCIE1
/SYS/MB/PCIE2
/SYS/MB/PCIE3
/SYS/MB/PCIE4
/SYS/MB/PCIE5
/SYS/MB/PCIE6
/SYS/MB/BAT
/SYS/MB/SPM
/SYS/PS0 (outer)
/SYS/PS1 (inner)
/SYS/MB
/SYS/DBP/HDD0 (lower left)
/SYS/DBP/HDD1
/SYS/DBP/HDD2 or /SYS/DBP/NVME0
/SYS/DBP/HDD3 or /SYS/DBP/NVME1
/SYS/DBP/HDD4 or /SYS/DBP/NVME2
/SYS/DBP/HDD5 or /SYS/DBP/NVME3
/SYS/DBP/HDD6
/SYS/DBP/HDD7 (right)
/SYS/MB/CM/CMP
/SYS/MB/EUSB_DISK
Links
"Replace the Top Cover" on page 157
"Servicing Memory Risers and
DIMMs" on page 83
"Servicing Memory Risers and
DIMMs" on page 83
"Servicing Memory Risers and
DIMMs" on page 83
"Servicing PCIe Cards" on page 107
"Servicing the Battery" on page 117
"Servicing the SPM" on page 121
"Servicing Power
Supplies" on page 77
"Servicing the
Motherboard" on page 129
"Servicing Drives" on page 59
"Servicing the
Motherboard" on page 129
