No.
LED or Control
4
Power Button
5
SP OK indicator
6
Fan Module Fault LED (amber)
7
Server Power Supply Fault LED
(amber)
8
Server Overtemp LED (amber)
Related Information
"Rear Panel Controls and LEDs" on page 30
■
"Checking for Faults" on page 21
■
Description
See
"Removing Power From the Server" on page 45
(System Power Button)" on page
Indicates these conditions:
■ Off – AC power might not have been connected to the power supplies, or an SPM
error has occurred and service is required.
■ Steady on – SP is running in its normal operating state. No service actions are
required.
■ Slow Blink – SP is initializing the Oracle ILOM firmware.
Indicates these conditions:
■ Off – Steady state, no service action is required.
■ Steady on – A fan module failure event has been acknowledged and a service action
is required on at least one of the fan modules.
Indicates these conditions:
■ Off – Steady state, no service action is required.
■ Steady on – A fault has been detected on one of the two power supplies.
Indicates these conditions:
■ Off – Steady state, no service action is required.
■ Steady on – A temperature failure event has been acknowledged. A temperature
limit has been exceeded, and a service action is required.
and
"Power On the Server
160.
Detecting and Managing Faults
Interpreting LEDs
29
