Add Memory To The Server - Oracle SPARC T8-1 Service Manual

Physical Location (Seen From Rear)
5
6
7
8
Right motherboard
9
10
11
12
Right memory riser
13
14
15
16
Related Information
"Memory Riser and DIMM Configuration" on page 83
■
"Checking DIMM Compatibility" on page 84
■
"Locate a Faulty DIMM (Fault Remind Button)" on page 90
■
"Locate a Faulty DIMM (Oracle ILOM)" on page 89
■
"Enable and Verify a DIMM" on page 103
■

Add Memory to the Server

These procedures require that you handle components that are sensitive to ESD.
Caution -
Follow antistatic practices
Customers can perform this procedure, but the server must first be completely powered down
and all power cords unplugged. See
information about cold-service procedures.
Memory Riser or DIMM FRU Name
/SYS/MB/CM/CMP/BOB30/CH1
/SYS/MB/CM/CMP/BOB20/CH0
/SYS/MB/CM/CMP/BOB20/CH1
/SYS/MB/CM/CMP/BOB10/CH1
/SYS/MB/CM/CMP/BOB10/CH0
/SYS/MB/CM/CMP/BOB00/CH1
/SYS/MB/CM/CMP/BOB00/CH0
/SYS/MB/CM/CMP/MR0 (riser)
/SYS/MB/CM/CMP/MR0/BOB01/CH1
/SYS/MB/CM/CMP/MR0/BOB01/CH0
/SYS/MB/CM/CMP/MR0/BOB21/CH1
/SYS/MB/CM/CMP/MR0/BOB21/CH0
to avoid damage or component failure.
"Component Service Categories" on page 43
Add Memory to the Server
for more
Servicing Memory Risers and DIMMs 87
