Oracle SPARC T8-1 Service Manual page 132

Remove the Motherboard
8. Remove the eUSB drive.
You will reinstall the eUSB drive on the new motherboard. See
Drive" on page
Open the fan cover and remove the fan modules.
9.
Disconnect the ribbon cables from the motherboard that go to the left and right
10.
LED indicator modules (panel 1).
The right LED indicator module include the front USB 2.0 ports. The left and right LED
indicator modules do not need to be removed to replace the motherboard.
11. Disconnect the cable from the server intrusion switch (panel 1).
132 SPARC T8-1 Server Service Manual • January 2022
113.
"Remove the eUSB
