Identify Disabled Components
Component Names Displayed by Diagnostic
Software
Use the information in this table to identify the name of a component that requires service.
Component
Battery
DIMMs
Drive backplane
Drives
Fan board
Fan modules
Memory risers
Motherboard
32 SPARC T8-2 Server Service Manual • June 2019
Oracle ILOM Target
/SYS/MB/BAT
/SYS/MB/CMn/CMP/MRn/BOBn/CHn/DIMM
/SYS/DBP
/SYS/DBP/HDD0 (bottom)
/SYS/DBP/HDD1
/SYS/DBP/HDD2
/SYS/DBP/HDD3
/SYS/DBP/HDD4
/SYS/DBP/HDD5 (top)
/SYS/FANBD
As viewed from front of server:
/SYS/FANBD/F0 (left)
/SYS/FANBD/F1 (center)
/SYS/FANBD/F2 (right)
/SYS/MB/CM0/CMP/MR0
/SYS/MB/CM0/CMP/MR1
/SYS/MB/CM0/CMP/MR2
/SYS/MB/CM0/CMP/MR3
/SYS/MB/CM1/CMP/MR0
/SYS/MB/CM1/CMP/MR1
/SYS/MB/CM1/CMP/MR2
/SYS/MB/CM1/CMP/MR3
/SYS/MB
Service Procedure
"Servicing the Battery" on page 111
"Servicing Memory Risers and
DIMMs" on page 89
"Servicing the Drive
Backplane" on page 159
"Servicing Drives" on page 63
"Servicing the Fan
Board" on page 137
"Servicing Fan
Modules" on page 75
"Servicing Memory Risers and
DIMMs" on page 89
"Servicing the
Motherboard" on page 147
